Ranch Work Shop

 This building is 25' wide x 65' long with a 14' eave height, 6:12 double slope roof pitch with a 2' overhang all around. Included are two 3070 insulated pre hung metal man doors, each with a 5' x 4', 6:12 canopy above them, one 12' x 14' insulated 2500 series chain operated roll up door on the front and two 10' x 10' insulated 2500 series manual roll up doors on the one side. There are also three 6030 and two 5040 insulated operable windows. The walls and roof are insulated with 3" PSKVR blanket insulation, covered with 26 ga PBR wall panels and 24 ga PBR roof panels. The siding color is "light stone", the roof is "Galvalume Plus" and the trim color is called "Rust".
